Laser Stone Cutting Machnine

Laser Stone Cutting Machine YTQQ-500 is good to cut marble and granite in a manual or automatic way. It has the ability to cut max 3200mm length 2000mm width and 80mm thickness. The table tilts automatically up to 85 degree. The blade holder head rotates 90 degree. The advantage of this machine is that it could be moved easily and occupied smaller space.

  • SHENGDA
  • QUANZHOU
  • 15 DAYS
  • 100 SETS/MONTH
  • Information
  • Video

Laser Stone Cutting Machine YTQQ-500 is good to cut marble and granite in a manual or automatic way. It has the ability to cut max 3200mm length 2000mm width and 80mm thickness. The table tilts automatically up to 85 degree. The blade holder head rotates 90 degree. The advantage of this machine is that it could be moved easily and occupied smaller space.



Technical Parameter:

Working thickness

80mm

Cutting disc diameter

350-500mm

Cutting length

3200mm

Cutting width

2000mm

Blade holder head rotating degree

90°

Table tilting degree

0-85°

Main motor power

15kW

Total power

21kW

Power requirement

3Phs 380V 50Hz

Water consumption

4m3/h

Installation space (L/W/H)

6000*3000*2600mm

Approximate weight

6000kg
