Bridge Saw Machine
Bridge Saw machine ZDCQ-400 (600) is good for cutting marble and granite in a manual or automatic way. It has the ability to cut max 3200mm length, 2000mm width and 65mm (160mm) thickness. The table tilts automatically up to 85 degree. Table rotates 90 degree (90°or 360°) automatically by hydraulic. It is the ideal machine to cut size to size.
- SHENGDA
- QUANZHOU
- 15 DAYS
- 100 SETS/MONTH
- Information
- Video
Bridge Saw machine ZDCQ-400 (600) is good for cutting marble and granite in a manual or automatic way. It has the ability to cut max 3200mm length, 2000mm width and 65mm (160mm) thickness. The table tilts automatically up to 85 degree. Table rotates 90 degree (90°or 360°) automatically by hydraulic. It is the ideal machine to cut size to size.
Technical Parameter:
ZDCQ-400 | ZDCQ-600 | |
Working thickness | 65mm | 160mm |
Cutting disc diameter | 350-400mm | 350-600mm |
Cutting length | 3200mm | 3200mm |
Cutting width | 2000mm | 2000mm |
Table rotating degree | 90° | 90° or 360° |
Table tilting degree | 0-85° | 0-85° |
Main motor power | 15kW | 18.5kW |
Total power | 21kW | 25kW |
Power requirement | 3Phs 380V 50Hz | 3Phs 380V 50Hz |
Water consumption | 4m3/h | 4m3/h |
Installation space (L/W/H) | 6000*5000*2800mm | 6000*5000*3000mm |
Approximate weight | 5500kg | 5500kg |
